EVO series is a compact, modern design amplifier that offer high quality audio reproduction for the audiophile and the everyday listener alike. All models feature fully variable crossovers with 12 dB per octave slopes, allowing you the ability to tailor the sound to best fit the speakers and your listening preferences.
FEATURE:
· Extreme high power and efficiency in a compact footprint
· Accurate audio reproduction
· 1 Ohm stable design (Mono Amps)
· Mil spec double sided & 4 layers PCB design with SMD parts
· Built-in noise reduction circuitry
· Full MOSFET with high grade switching devices
· 0~12DB variable bass boost
· Next generation advanced 5 way protection circuitry
· With bandpass adjustment
· Full range frequency response is 10Hz-20KHz
| MODEL | EVO1000.1 | EVO2000.1 | EVO800.4 | EVO800.4 Plus | EVO1200.4 | EVO1200.4 Plus | EVO2400.4 | EVO2400.4 Plus |
| 1OHM RMS 1% THD | 1200Wx1 | 2000Wx1 | N/A | 200Wx4 | N/A | 300x4 | N/A | 420x4 |
| 2OHM RMS 1% THD | 800Wx1 | 1100Wx1 | 200Wx4 | 130Wx4 | 300W*4 | 220W*4 | 420W*4 | 300W*4 |
| 4OHM RMS 1% THD | 550Wx1 | 700Wx1 | 132Wx4 | 85Wx4 | 200W*4 | 120W*4 | 300W*4 | 200W*4 |
| SIZE(mm) | 135*132*53 | 169*132*53 | 127*132*53 | 127*132*53 | 178*132*53 | 178*132*53 | 208*132*53 | 208*132*53 |
| SIZE(inch) | 5.3*5.2*2.1 | 6.65*5.2*2.1 | 5*5.2*2.1 | 5*5.2*2.1 | 7*5.2*2.1 | 7*5.2*2.1 | 8.2*5.2*2.1 | 8.2*5.2*2.1 |
EVO1000.1(1OHM)
EVO2000.1(1OHM)
EVO800.4(4OHM)
EVO1200.4(4OHM)
EVO2400.4(4OHM)
